ChamSys QuickQ 30

SKU: QUICKQ30 Category: Tags: , , , ,


The QuickQ 30 is part of ChamSys QuickQ range of user friendly lighting control consoles. The QuickQ 30 is the perfect choice console for control of dimmer, LED colour mixing and moving light fixtures. The console features a large 9.7 inch touch screen utilising a smartphone like interface for setup, programming and playback of your show.

The console can automatically detect, patch and configure RDM compliant fixtures and also features in-built WIFI capabilities enabling remote connections to the free QuickQ app available on iOS, Android & Windows tablets and phones. Easily connect the app by simply scanning the QR code on the console display.

The console has easy-to-understand buttons and faders, simple colour selection and intensity control tools, a large touch screen with zooming and scrolling at your fingertips, as well as a simple cue/chase system for playback. Specifically aimed at the novice user, the QuickQ interface easily leads you through setup, programming and operation of the console.

The console has a free to download offline programming software available for Mac and Windows that includes the ChamSys MagicVis visualiser. You can program your show on your computer, save it onto a flash drive and load it onto the QuickQ console.

QuickQ uses ChamSys extensive and continuously updated personality library with over 26,000 personalities.

QuickQ shows are compatible can be loaded onto any MagicQ system allowing future progression onto ChamSys more advanced MagicQ range of consoles.

Key Features:

Modelled on smartphone icon interfaces for ease of use
Intuitive interface allowing simple control of all fixture attributes
The interface supports gestures such pinch zoom and scrolling
Easily connect to the remote app on iOS & Android devices via inbuilt Wi-Fi

40 multi-function fixture faders with 3 different modes – Fixture, Group and Cue
10 multi-cue Playback faders, which are legended on screen
The console features a dedicated Grand Master fader for overall level control

A dedicated “colour control area” with Hue and Saturation encoders
Select from inbuilt palettes and gel libraries using the touch screen
Built in colour picker for use with LED fixtures

Hardware Specifications:

Universes supported: 4
Direct DMX Outputs 5-Pin XLR: 3
Master Playback Faders: 10
Multi-Function Fixture Faders: 40
Bump Buttons: Yes
Attribute Encoders: 4
Dedicated Hue/Saturation Encoders: Yes
Inbuilt 9.7” Multi-touch Display: Yes
External Monitor: 1920 x 1080 HDMI
Inbuilt Wi-Fi: Yes
Network Port: 1
USB Ports: 2
Audio Input: 1
Audio Output: 1
MIDI Ports in/out: Yes

Software Specifications:

Max Number of DMX Channels: 2048
Max Number of Fixtures Supported: 2048
Max Number of Cue Stacks: 10
Max Number of Chases: 10
Midi & Midi Timecode Supported: Yes
OSC Supported: Yes
RDM Autopatch for fast show patching
Fixture library of over 30,000 fixture files
Built in FX generator
Colour picker and Gel inbuilt Gel library
Offline designer software available for Windows and Mac

Weights and Dimensions:

Width: 760mm (29.9 inches)
Depth: 350mm (13.8 inches)
Height: 106mm (4.2 inches)
Weight: 6.1kg (13.44 lb)

Flight Cased:
Width: 860mm (33.8 inches)
Depth: 490mm (19.3 inches)
Height: 220mm (8.7 inches)
Weight (console in flightcase): 20kg (44.09 lb)
