Description
Ensure larger installations don’t lose their impact with the PixLite® R2F-S pixel control receiver. When paired with the T8-S Mk3 transmitter, the receiver has the power to drive up to 2,040 RGB pixels.
The PixLite® R2F-S comes complete with all the protection you need for peace of mind with professional installations. Paired with a PixLite® T8-S Mk3 controller, the PixLite® R2F-S receives differential (long-distance) data and converts it into a pixel ready signal.
When it comes to creating unforgettable, professional-grade displays over longer distances, you’ll find it impossible to ignore the benefits of the slimline form and ease of use that you get with the PixLite® R2F-S receiver.
The PixLite® R2F-S receiver features industrial strength fault protection on all inputs and data outputs. This makes this pixel receiver device highly reliable in a wide range of settings, and greatly reduces the likelihood of equipment failure over time. Short circuit and ESD protection, along with protection against common DC voltage levels, will grant you peace of mind on your next commercial or industrial installation. Each output also includes a 7.5A mini blade fuse which helps preserve the safety of the device. Plus, a built-in spare fuse ensures there’s always a quick replacement on hand.
Features
Industrial grade fault protection
Receives data up to 300+m from PixLite T8-S
Din-rail and wall mountable
Sleek design with flip lid access to all fuses
Compact form
2 pixel outputs (6 Universe per output)
Expanded mode provides 4 data only outputs (3 Universe per output)
Distances of up to 300m (using R2/R4 receivers)
Over 60+ pixel protocols supported
Configure using Advatek Assistant
Electrical fault protection on all ports
Gamma correction for pixels of all resolutions.
Dithering for higher resolution pixel control.
Extremely fast refresh rates.
Dynamic adjustment.
SPECIFICATIONS
data inputs (from transmitter): 1 x RJ45
Input power: 5v – 24v dc
Per output current limit: 7.5a
Total current limit: 15A
PHYSICAL
Dimensions: 95mm x 78mm x 33mm
Weight: 0.2kg
Ambient Operating Temperature: -20°c to +55°c
Housing Material: ABS
Mounting Options: Wall & din-rail mountable
