PixLite R4D-S Long Range Receiver

SKU: ASTERA-FP6-HYDRA-1-1-1 Category: Tags: , , , , , , , , , , , ,


When you need to go big, go R4D-S. Designed to bring sizable projects to life, this pixel control receiver works together with the T8-S Mk3 transmitter to drive up to 2,040 RGB pixels for larger-scale installations.

For professionals looking to make that ‘peace of mind’ purchase, it has to be the PixLite® R4D-S. This controller ensures that installing and running complex, long-distance displays is easy — every time.

When used in tandem with the PixLite® T8-S Mk3 controller, the PixLite® R4D-S serves as the receiver of differential pixel data, converting it into a pixel ready signal. A long-distance capability is all you need to open up a broad range of possibilities and make unforgettable displays possible.

The PixLite® R4D-S Receiver features industrial strength fault protection on all inputs and pixel outputs, making it far less prone to failure over time. While short circuit and ESD protection, as well as protection against common DC voltage levels, provides safety for commercial and industrial installations.

Each output also includes a 7.5A mini blade fuse which helps protect the LEDs and power supply, keeping the installation safe. A built-in spare fuse ensures there is always a quick replacement on hand.


Industrial grade fault protection
Receives data up to 300+m from PixLite T8-S
Din-rail and wall mountable
Sleek design with flip lid access to all fuses
Compact form
4 pixel outputs (data only – 3 Universe per output)
Unexpanded mode delivers 2 Clocked Outputs (6 Universe per output)
Distances of up to 300m (using R2/R4 receivers)
Over 60+ pixel protocols supported
Configure using Advatek Assistant
Electrical fault protection on all ports
Gamma correction for pixels of all resolutions.
Dithering for higher resolution pixel control.
Extremely fast refresh rates.
Dynamic adjustment.


data inputs (from transmitter): 1 x RJ45
Input power: 5v – 24v dc
Per output current limit: 7.5a
Total current limit: 30A


Dimensions: 95mm x 78mm x 33mm
Weight: 0.2kg
Ambient Operating Temperature: -20°c to +55°c
Housing Material: ABS
Mounting Options: Wall & din-rail mountable
