PixLite T8-S Long Range Transmitter Mk3

SKU: ASTERA-FP6-HYDRA-1-1 Category: Tags: , , , , , , , , , , , ,

Description

Unbeatable power doesn’t have to come at a price. The PixLite® T8-S Mk3 long range pixel controller is ideal for controlling pixels over a large area. Eight outputs can connect to eight receivers, driving up to 16,320 RGB pixels, and receivers can be placed up to 300 meters from the transmitter.

The PixLite® T8-S Mk3 is a powerful long-range pixel LED controller that replaces Advatek’s bestselling T8-S Mk2 controller. This new generation controller was developed to meet overwhelming demand from our customers for an even more powerful long-range solution in a reliable, user-friendly system. The PixLite® T8-S Mk3 transmits up to 96 universes of data to eight PixLite® R2/R4 receivers at distances of up to 300m – perfect for any professional installation where the LEDs will be separated by some distance.

Advatek’s Mk3 family of pixel controllers is tested and certified for professional and commercial applications. Wherever your project, you can confidently deploy an Advatek pixel solution with class-leading value, performance and features. The Mk3 family is protected electrically, won’t interfere with other building management and control systems or affect other sensitive RF, network and communications infrastructure.

Features

96 universes of Art-Net or sACN
Distances of up to 300m (using R2/R4 receivers)
Over 60+ pixel protocols supported
Configure using Advatek Assistant
Electrical fault protection on all ports
Gamma correction for pixels of all resolutions.
Dithering for higher resolution pixel control.
Extremely fast refresh rates.
Dynamic adjustment.

SPECIFICATIONS

Ethernet port: 2 x 10/100/1000 mbit/s
Data outputs (to receivers): 8 x rj45
Microsd card slot (for Advatek SHOWTime™)
Auxiliary port: 1 x rs485 input/output (for DMX512 In/Out)
Input power: 100v-240v ac

PHYSICAL

Dimensions: 169mm x 221mm x 42mm
Weight: 1.1kg
AC fuse: 1A M205
Ambient Operating Temperature: -10°c to +60°c
Housing Material: Aluminium
Mounting Options: Direct panel, wall & rack mountable
