Description
The SR-SPI-OLED is a smart LED pixel controller to control digital IC RGB/RGBW LED strip lights with SPI signal.
The LED controller is capable of addressing up to 1020 pixels and supports 38 types of driving IC.
The number of pixel to be addressed and IC type that drives your LED lights can be configured via the OLED Panel.
FEATURES
SPI signal output for control of RGB/RGBW pixel lights
DMX512 controllable and RF/WiFi remote controllable
Capable of addressing up to 1020 pixels
The built-in, backlit OLED panel allows for easy configuration of most settings
Four push buttons available for control of the OLED functions
Supports 38 types of driving IC
RGB/RGBW colour order configurable
512 DMX decoding channels
Support max. 3060 output channels configurable
CONNECTIONS
Terminal Connections for DMX, Power Input, LED Output
ELECTRICAL SPECIFICATIONS
Power Input: 5V, 12V-24V DC
Voltage Range: 12V-36V DC
Input Current: 0.2A MAX
Output: SPI Signal
Power Consumption 480W (12V) – 960W (24V)
PHYSICAL SPECIFICATIONS
Dimensions (HxWxD): 46mm x 178mm x 21mm
IP Rating IP20
RIGGING
Mounting Options Via screw holes
IC PIXEL PROTOCOLS
WS2801, WS2803, WS2811L, WS2811H, WS2812, WS2813
LPD1101, LPD6803, LPD8803, LPD8806
TM1803, TM1804L, TM1804H, TM1809L, TM1809H, TM1812, TM1825L, , TM1825H, TM1829L, TM1829H
UCS1903L, UCS1903H, UCS1909L, UCS1909H, UCS1912, UCS2903, UCS2909L, UCS2909H, UCS2912, UCS6909, UCS6912
P9813
D705
TLS3001, TLS3002
APA102, APA104
SK6812
