Description
The Chauvet Net-X II is a versatile rack or truss mount Ethernet-to-DMX node, it has two 5-pin DMX inputs and eight 5-pin DMX outputs, all optically isolated.
The eight 5-pin DMX outputs can be individually assigned to either of the two DMX inputs, or ArtNet/sACN Universes, allowing a mix of sources in a single device. Merging is supported using HTP or LTP merging methods on each output. The Net-X features 2 Neutrik etherCON Network Ports, to facilitate linking of nodes.
Features
8 Universes (4096 DMX Channels)
8 DMX Output or Input Ports
Supports RDM
2 x 5 Pin XLR DMX Inputs
DMX Merging between Inputs and ArtNet
Neutrik etherCON Through (10/100 T-Base)
Hardware
Neutrik powerCON True1 input
Voltage Range: 100V – 240V 50/60 Hz (auto-ranging)
Internal Switching Power Supply
Current: 0.06A @230V, 0.09A @110V
Power Consumption: 14W @230V, 11W @110V
Fuse: F 1A 250V
Protection Class: IP20 Dry Location
Made from Steel
Mounting Options M12 Threading Mounting Hole, Rack Mount Ears
Safety Bond Safety Cable Attachment
Max Ambient Temp 40°C (104°F)
