Description
1 Universe Wireless DMX & RDM Receiver, utilising the award-winning CRMX technology from LumenRadio.
Features a wide voltage input from 5V to 28V (enabling it to be powered by USB, Power Supplies or Batteries), an on-board voltage regulator & thermal cut off protection.
FEATURES
Universes 1
Channels 512
DMX Ports 1 5-Pin XLR Output
PROTOCOLS
DMX 512 USITT DMX512, DMX512(1990) & DMX512-A
Wireless DMX LumenRadio CRMX (W-DMX G2/G3/G4 Compatibility)
RDM RDM ANSI E1.20
WIRELESS
Operating Frequency 2.4GHz (Operational frequency range: 2402-2480 MHz)
Antenna RP-TNC male
CONNECTIONS
DMX Output 1 x 5 Pin XLR
Power 2.1 DC Power Jack
ELECTRICAL SPECIFICATIONS
Power Input 5V / 12V / 24V
Voltage Range 5V – 28V DC
Power Supply External
Current ≤300mA
PHYSICAL SPECIFICATIONS
IP Rating IP20
THERMAL
Max Ambient Temp 50°C (122°F)
Min Ambient Temp -20°C (-4°F)
Operating Humidity 0-90% non-condensing
