Description
The DMX USB Pro MK2 can control up to 1024 DMX channels or receive them through one simple USB 2.0 connection. It interacts with a broad array of supported 3 rd party commercial and free software running on either PCs or Macs.
The Pro MK2 introduces a new standalone playback function. Alongside it, you have the option to use physical MIDI when used in combination with the PRO2 DB15- the 3DMX+2MIDI breakout cable.
The DMX USB Pro MK2 features internal frame buffering for consistent DMX generation when outputting, you can plug your Pro MK2 directly into a fixture for quick on-site RDM analysis, using ENTTEC’s free Pro Manager software,
Each DMX port features 1500V full isolation for both Data and power lines. You can rest assured that your computer will be protected from any stray voltages and faults that may occur on the DMX line.
FEATURES
Universes 2
MIDI & OSC MIDI Input/Output
DMX Ports 2 x Output, 1 x Input
USB Ports 1 x Micro USB B Male Connector
PROTOCOLS
DMX 512 Supported
RDM Supported
SOFTWARE
Operating System Windows, Mac, Linux
Compatible Software ENTTEC Pro Manager, Chamsys MagicQ, Capture
CONNECTIONS
DMX Input 1 x 5 Pin XLR
DMX Output 2 x 5 Pin XLR
USB 1 x Micro USB B Male Connector
MIDI 1 x Input, 1 x Output
Comms Port 1 x 15-Pin breakout Connector
ELECTRICAL SPECIFICATIONS
Current 500mA supplied by USB
PHYSICAL SPECIFICATIONS
Materials Anodised Aluminum
THERMAL
Max Ambient Temp 50° C
Min Ambient Temp 0° C
