Description
The Estrella Orbita LED Driver is an ideal LED driver for LED tape on sets, with Flicker Free control for TV & Film
It features 4 channels of constant voltage LED tape control (10A per channel), and it can drive both 12V and 24V LED tape.
FEATURES
Channels 4 @ 10A per channel
DMX Ports XLR5 In/Out & RJ45 In/Out
Frequency Range 10KHz PWM
PROTOCOLS
DMX 512 DMX512 1990
CONNECTIONS
DMX Input XLR5 & RJ45
DMX Output XLR5 & RJ45
Power Terminal Connection
ELECTRICAL SPECIFICATIONS
Power Input 12V & 24V DC
Voltage Range 12V-24V DC
Power Supply External
Current 40A Total (10A per Channel)
Power Consumption 480W (12V) – 960W (24V)
PHYSICAL SPECIFICATIONS
IP Rating IP40
RIGGING
Mounting Options Via 4 screw holes
THERMAL
Max Ambient Temp 70° C (158° F)
Min Ambient Temp 0° C (32° F)
