Description
MIMIK 120 is an image based video lighting tile that mirrors video content while applying a higher tonal and color rendering range. MIMIK delivers extended spectral bandwidth and cinematic color fidelity when lighting talent and set elements in virtual production environments.
Patented Kino Flo technology translates an incoming RGB video signal into five individual emitters (warm white, cool white, red, green and blue), generating synchronized foreground lighting that creates the utmost realism on virtual sets.
Embodied in a lightweight carbon fiber frame, MIMIK adapts to on-set configurations with easy mobility. Controlled by the Megapixel VR HELIOS LED processor, MIMIK expands real-time and post-production options, delivering 10,000 NITS, along with the ability to shoot as high as 900 frames per second and offer as many as 30 Alpha channels at 30 frames per second.
This revolutionary full spectrum LED image based lighting solution enables latency-free synchronization to an LED volume along with the versatility of optional control from a lighting desk.
Specifications:
Controlled thru Megapixel Helios.
Receiver Card: 2 x PX1 (Megapixel)
Max. Stacking : 5 Tiles high, no limit to width
Tile Linking: Corner blocks, 2-way and 4-way locking
Curving (Concave & Convex): Concave (With attachment)
Max Alpha Channels: 30 at 30 fps
Pixel Pitch: 10mm
Pixel Count: 7,200 pixels (120 x 60)
Pixel Construction: 5 LEDs per pixel – Warm White 2700K, Cool White 6500K, Red, Green, Blue
LED Package: SMD 5050 – Black Body
Viewing Angle Horizontal / Vertical: 140° / 140°
LDM (LED Display Module): 8 Total – Magnetically attached – Front side Serviceable
LDM Transparency: Solid – Black front
Scan Ratio: 1/3
Refresh Rate: 30kHz (30,720Hz)
Gray Scale: 16-bit minimum (65,535 steps)
Frames Per Second: 900 fps
Max Brightness Calibrated: ~10,000 nits
Input Voltage VAC: 100~240VAC; 50/60Hz
Power Consumption Max / Average: 400W / 200W (Varies based on video content)
Frame Material: Carbon Fiber
IP Rating: IP20 – Indoor
Operational Temp / Humidity: -10°~45°C, 10~90%RH / 14°~113°F, 10~90%RH
Weights and Dimensions:
Width 1200mm (47.2 inches)
Depth: 600mm (23.6 inches)
Height: 80mm (3.2 inches)
Weight: 12.5kg (27.6 lbs)
