Description
Titan Tube is the ultimate LED tube for filmmakers, studios, event technicians and any creative person. It emits powerful, tunable whites with ultra-high color rendering as well as colored light which can be applied to individual pixels or the whole tube. The tube offers unlimited range of usage; indoor or outdoor, AC-powered or on battery, on the go with the AsteraApp, with wired or wireless DMX.
SPECIFICATIONS
LED Engine: Titan LED Engine
Colors: RGBMintAmber
Total LED Power: 72 W
LED Power draw: 48 W
Luminous Flux 3200K: 2535 Lumens
Luminous Flux 4000K: 2900 Lumens
Light Output 3200 K @ 1m: 708 Lux
Light Output 4000 K @ 1m: 785 Lux
CRI(Ra)/TLCI 3200-6500K*: ≥96
Beam Angle: 135° x 115°
Field Angle: 175° x 160°
Strobe: 0 – 25 Hertz
Pixel: 16
Battery Runtime: Up to 20 hours
Battery Runtime (max. Brightness): 1 h 45 m
Battery Lifetime: 70 % after 300 cycles
Charging Time (nominal): 3 hours
DC Input: 24 VDC – 2 A
DC Connector: 5.5 mm x 2.1 mm
Wired DMX: Yes (via FP1-PWB / FP3-DTL / PWB-2-86)
CRMX Receiver: Built-in
BluetoothBridge BTB: Yes
Wireless Protocols: CRMX, UHF, Bluetooth, WiFi
Wireless Range: CRMX/UHF up to 300 m (330 yds) Bluetooth up to 3 m (3.3 yds)
Infrared Control: Yes
PHYSICAL
Dimensions (L x Ø): 1035 mm x Ø 43 mm (40.7″ x Ø 1.7″)
Weight: 1.35 kg (3 lbs)
Ambient Operating Temperature: 0 – 40 °C (32 – 104 °F)
IP Rating: IP65 (only with FP1-SP)
Housing Material: Polycarbonate, metal end caps
Mounting Options: 2x M5 thread, 2x Holder (with 2x M5 and 1x 1/4″-20UNC thread), 1x TubeStand
