Description
Beam shaping with six included light modifiers and a large range of mounting options make HydraPanel more flexible than any other product in its class. The full-spectrum Titan LED Engine generates an impressive 1300 Lumen output while running on battery power.
SPECIFICATIONS
LED Engine: Titan LED Engine
Colors: RGBMintAmber
Total LED Power: 25 W
LED Power draw: 17 W
Luminous Flux 3200K: 1 102 Lumens
Luminous Flux 4000K: 1 287 Lumens
Luminous Flux 5500K: 1 298 Lumens
Light Output 3200 K @ 1m: 443 Lux
Light Output 4000 K @ 1m: 512 Lux
Light Output 5500 K @ 1m: 516 Lux
CRI(Ra)/TLCI 3200-6500K*: ≥96
Beam Angle: 110° x 100°
Field Angle: 150° x 145°
Strobe: 0 – 25 Hertz
Pixel: 6
Battery Runtime: Up to 20 hours
Battery Lifetime: 70 % after 300 cycles
Charging Time (nominal): 1h 45 m
DC Input: 24 VDC – 0..85 A
DC Connector: 5.5 mm x 2.1 mm
Wired DMX: Yes (via FP1-PWB/ FP3-DTL/ PWB-2-86)
CRMX Receiver: Built-in
BluetoothBridge BTB: Yes
Wireless Protocols: CRMX, UHF, Bluetooth, WiFi
Wireless Range: CRMX/UHF up to 300 m (330 yds) Bluetooth up to 3 m (3.3 yds)
Infrared Control: Yes
ControlSync: Yes
TouchSlider: Yes
PHYSICAL
Dimensions: 166 mm x 85 mm x 43.5 mm (6.53″ x 3.34″ x 1.71″)
Weight: 604 g (1.3 lbs)
Ambient Operating Temperature: 0 – 40 °C (32 – 104 °F)
IP Rating: IP65 with power cable (wireless with PB15-PLG)
Housing Material: Polymer & Metal
Mounting Options: 2 x ColdShoe 3 x M5 thread 1 x SafetyWire Eyelet
