Description
Astera’s Wireless PixelBar is a linear wash fixture with built-in battery pack. Each of its LEDs can be individually addressed and offers ultra-high color rendering, digital color calibration and a native 21° beam. Thanks to its smart stands, hanging bracket, connectable endcaps and the integrated airline track it can be quickly assembled in numerous ways and is suitable for a wide variety of applications such as concert/touring, corporate events, TV etc.
SPECIFICATIONS
LED Engine: Titan LED Engine
Colors: RGBMintAmber
Total LED Power: 80 W
LED Power Draw: 40 W
Luminous Flux 2700K: 1800 Lumens
Luminous Flux 3200K: 2230 Lumens
Luminous Flux 5500K: 2265 Lumens
Light Output 2700 K @ 1m: 8995 Lux
Light Output 3200 K @ 1m: 11060 Lux
Light Output 5500 K @ 1m: 11010 Lux
CRI (Ra)/ TLCI 3200- 6500 K*: ≥96
Beam Angle: 21°
Field Angle: 42°
Strobe: 0 – 25 Hertz
Pixels: 8
Battery Runtime: up to 20 hours
Battery Runtime (max. Brightness): 2 h 50 m
Battery Lifetime: 70 % after 300 cycles
Charging Time (nominal): 5 hours
AC Input: 96-264 VAC, 50/60 Hertz, 2A, 49W
AC Connector: PowerCON TRUE1 IN/OUT
Wired DMX: Yes (via 5-pin XLR)
CRMX Receiver: Built-in
BarConnect+: Yes
Wireless Protocols: CRMX, UHF
Wireless Range: CRMX/UHF up to 300 m (330 yds)
Infrared Control: Yes
PHYSICAL
Dimensions without hook (L x W x D): 500 mm x 165 mm x 65 mm (19.7″ x 6.5″ x 2.6″)
Dimensions with hook (L x W x D): 520 mm x 165 mm x 65 mm (20.5″ x 6.5″ x 2.6″)
Weight: 4.5 kg (9.9 lbs)
Ambient Operating Temperature: 0 – 40 °C (32 – 104 °F)
IP Rating: IP65
Housing Material: Aluminium
Mounting Options: Airline Track, 2x AX2 Feet (with 3/8″ thread)
